Type: | Residential |
Heat Exchanger: | Stainless Steel |
Fuel: | Gas Fired (Natural Gas or LP) |
Heating Input: | 13.6-120/20-150 MBH |
Maximum Domestic Hot Water Input: | 136/200 MBH |
Efficiency (AFUE) | 95% |
Venting: | Direct Vent |
Ignition: | Direct Spark |
Trim: | Water |
Domestic Water: | Included |
Burner: | Modulating with 10:1 turndown ratio |
Configuration: | Packaged |
Notes: | Low Loss Header included 2″ venting standard 5-year parts warranty Serviceability |
Space Heating Ratings | Domestic Hot Water (DHW) Ratings 1 | |||||||||
Model Number | Input (MBH) Min-Max |
Heating Capacity, MBH |
Net AHRI Water, MBH3 |
AFUE, % | Input (MBH) Min-Max2 |
Max Draw GPM | Min.4 | Approx. Shipping Weight (lbs) | ||
70°F Rise | 77°F Rise | 90°F Rise | ||||||||
Combi Model PHNTM2136C | 13.6-120 | 112 | 97 | 95.0 | 13.6-136 | 3.7 | 3.4 | 2.9 | 0.5 | 112 |
Combi Model PHNTM2200C | 20-150 | 141 | 123 | 95.0 | 13.6-136 | 5.2 | 4.7 | 4.0 | 0.5 | 135 |
MODEL NUMBER | DEPTH (INCHES) | HEIGHT (INCHES) | WIDTH (INCHES) |
PHNTM2136C | 16.3 | 29.8 | 17.8 |
PHNTM2200C | 20.4 | 29.8 | 17.8 |
CONNECTION SIZE | |
SUPPLY/RETURN | 1-1/4″ MPT |
DHW | 3/4″ MPT |
GAS | 1/2″ MPT |
VENT | 2″ STD (3″ w/increaser) |
