Specifications:
H.P. | 1/60 |
Speeds | 1 |
Volts | 230 |
Amps | 0.55 |
Rotation | CWLE |
RPM | 3000 |
Amps at Free Air | 0.6 |
Bearings | Ball |
Diameter (In.) | 3.3 |
Enclosure | Open |
RPM at Free Air | 3100 |
Static Pressure 0.1 in. | 71 |
Static Pressure 0.2 in. | 138 |
Static Pressure 0.3 in. | 66 |
Static Pressure 0.4 in. | 63 |
Static Pressure 0.6 in. | 54 |
Static Pressure 0.7 in. | 37 |
Static Pressure 0.8 in. | 43 |
Motor Type | Shaded Pole |
Frame | 3.3 |
Overload | Automatic |
Phase | 1 |
Hertz | 60 |
Replaces:
A.O. Smith | 322P859 |
A.O. Smith | 322P859 |
Amana | D69964-3 |
Amana | D69964-4 |
Amana | D6996403 |
Amana | D6996404 |
Armstrong | 35035B001 |
Armstrong | 35035B1 |
Armstrong | 35HWC181 |
Armstrong | 36HWC24A |
Armstrong | 36HW |
Armstrong | 36HWC18A |
Armstrong | 36HWC241 |
Armstrong | 66HWC301 |
Armstrong | 60HW |
Armstrong | 60HWC181 |
Armstrong | 60HWC18A |
Armstrong | 60HWC301 |
Armstrong | 60HWC241 |
Armstrong | 60HWC24A |
Armstrong | 60HWC30A |
Armstrong | 66HWC24A |
Armstrong | 66HW |
Armstrong | 66HWC181 |
Armstrong | 66HWC18A |
Armstrong | 66HWC241 |
Armstrong | 48HW |
Armstrong | 48HWC181 |
Armstrong | 48HWC18A |
Armstrong | 48HWC241 |
Armstrong | 48HWC24A |
Fasco | A081 |
Fasco | 7021-5510 |
Fasco | 7021-10263 |
Fasco | 7021-10264 |
Fasco | AO81 |
Franklin | F3670-1 |
Johnson | 8973C |
Lennox | 8973C |
Magic Chef | HWC Series |
Magic Chef | 48HWC181 |
Magic Chef | 48HWC24A |
Magnetek | 464 |
Universal | 999 |
Universal | 464 |
Universal | DE3L038 |
Williamson | 4MH16 |
Williamson | 25-568 |
Williamson | 02-568 |
